ON-8712G-4XFPI
The Optech Network Solutions ON-8712G-4XFPI is a DIN-rail industrial managed Layer 3 Ethernet switch designed for high-bandwidth industrial networks requiring Gigabit connectivity, 10G fiber uplinks, and PoE. The switch provides 8 × 10/100/1000BASE-T RJ-45 PoE ports supporting IEEE 802.3af/at and 4 × 10G SFP+ uplink ports. Layer 3 functionality includes static routing and NAT, while industrial networking features include high-speed ring redundancy, RSTP/STP, ERPS, VLAN, QoS, network security, and remote management. Its dual 48–57 VDC power inputs, relay output, DIN-rail/wall-mount installation, and wide operating temperature range make it suitable for industrial, utility, surveillance, automation, and other demanding network environments.
Key Features
8 × Gigabit PoE Ports + 4 × 10G SFP+ Uplinks Eight 10/100/1000BASE-T PoE ports support IEEE 802.3af/at, complemented by four high-speed 10G SFP+ fiber interfaces.
Industrial Layer 3 Switching Supports static routing and NAT for networks requiring Layer 3 connectivity and traffic management.
High-Speed Network Redundancy Supports X-Ring Pro, RSTP/STP, and ERPS for resilient industrial network architectures.
Comprehensive Network Security & Management Includes 802.1X, MAB, ACL, RADIUS, TACACS+, SNMPv3, HTTPS, SSH, SFTP, DHCP, and centralized network monitoring capabilities.
Industrial-Grade Design with Redundant Power DIN-rail/wall-mount installation, -40°C to +75°C operating temperature, IP40 metal enclosure, dual 48–57 VDC power inputs, and 240 W PoE power budget.
Technical Specifications
| Specification | ON-8712G-4XFPI |
|---|---|
| Product Type | Managed Industrial Layer 3 PoE Ethernet Switch |
| Model | ON-8712G-4XFPI |
| Ethernet Ports | 8 × 10/100/1000BASE-T/TX RJ-45 |
| PoE Ports | Port 1–8, IEEE 802.3af/at |
| PoE Power Budget | 240 W |
| 10G Uplink Ports | 4 × SFP+ (Mini-GBIC) |
| Copper Port Features | Auto-Negotiation, Full/Half Duplex, Auto MDI/MDI-X |
| Console Port | RS-232, RJ-45 |
| Digital Input | 1 channel |
| Digital Input — Logic 1 | +13 to +30 V |
| Digital Input — Logic 0 | -30 to +3 V |
| Maximum Digital Input Current | 8 mA |
| USB Interface | 1 × USB Type-A |
| Relay Output | 1 × relay output, 1 A @ 24 VDC |
| Power Connector | 8-pin screw terminal block |
| Power Input | Dual 48–57 VDC |
| Recommended PoE Supply | 53–57 VDC for IEEE 802.3at operation |
| System Power Consumption | 24 W @ 54 VDC |
| Switching Capacity | 96 Gbps |
| Transmission Rate | 71.2 Mpps |
| MAC Address Table | 16K |
| Jumbo Frame | 12,288 bytes |
| Maximum IGMP Groups | 256 |
| Maximum VLAN Groups | 256 |
| VLAN ID Range | 1–4094 |
| VLAN | IEEE 802.1Q, IEEE 802.1ad QinQ VLAN Stacking |
| Port Mirroring | 1-to-1, N-to-1; up to 4 mirror sessions |
| RSPAN | Supported |
| Multicast | IGMP Snooping v1/v2/v3, MLD Snooping, IGMP Immediate Leave |
| Storm Control | Broadcast, Multicast, Unknown Unicast |
| LLDP | IEEE 802.1ab LLDP, LLDP-MED |
| Industrial Protocol | Modbus/TCP |
| Link Aggregation | IEEE 802.3ad Dynamic Port Trunking, Static Port Trunking |
| QoS Scheduling | WRR, Strict Priority, Hybrid Priority |
| Priority Queues | Up to 8 |
| Class of Service | IEEE 802.1p, IP ToS, DSCP |
| Rate Limiting | Ingress and Egress |
| Layer 3 Routing | Static Routing, NAT |
| Network Redundancy | X-Ring Pro, STP, RSTP, MSTP, ERPS |
| Port Security | Static/Dynamic MAC, MAC Learning Limit, MAC Violation Notification |
| Authentication | 802.1X Port/MAC-based, MAB |
| Authentication Servers | RADIUS, TACACS+ |
| IP Security | IP Source Guard, DHCP Snooping, ARP Spoofing Prevention |
| ACL | IP-ACL, MAC-ACL; up to 128 entries |
| Management Protocols | SNMP v1/v2c/v3, Web, Telnet, RMON |
| Management MIBs | Standard MIB-II, Private MIB, Ethernet-Like MIB, RMON MIB |
| Secure Management | SSH 2.0, SSL |
| Software Upgrade | TFTP, SFTP, HTTP, Dual Image |
| Time Synchronization | SNTP Client |
| DHCP | Client, Server, Relay, Option 66/67/82 |
| Network Monitoring | NMS support for remote monitoring and management |
| Enclosure | Metal Shell |
| Protection Class | IP40 |
| Installation | DIN-Rail, Wall-Mount |
| Dimensions (W × H × D) | 57.5 × 152 × 116 mm |
| Operating Temperature | -40°C to +75°C |
| Storage Temperature | -40°C to +85°C |
| Copper SFP Operating Limitation | -40°C to +50°C when using copper SFP ×4 |
| Relative Humidity | 5–95% RH, non-condensing |
| Overcurrent Protection | Supported |
| Reverse Polarity Protection | Supported |
| LED Indicators | PWR1, PWR2, SYS, Alarm, R.M.; Link/Speed/Activity/PoE |
| Power Redundancy | Dual DC Power Inputs |
| Power Supply Range | 48–57 VDC |
| Certifications / Standards | Source-referenced: UL 62368, CE, CISPR 32, FCC Part 15B Class A, IEC 61000 series, EN 61000-6-2/-6-4, IEC 60068 series |
