Protocol Converter
Prime Connect 4055s
The Optech Network Solutions Prime Connect 4055s is a compact Gigabit Ethernet media converter designed to connect copper Ethernet networks with fiber-optic infrastructure. It provides a 10/100/1000 Mbps RJ45 Ethernet interface and a modular SFP interface, allowing the fiber connection to be selected according to the required fiber type, connector and transmission distance. The modular SFP architecture provides flexibility for different network deployments, including multi-mode and single-mode fiber applications. The device supports automatic Ethernet negotiation and provides front-panel LED indicators for convenient monitoring of power, link and network activity.
Key Features
Gigabit Ethernet connectivity through a 10/100/1000 Mbps RJ45 interface
Gigabit Ethernet connectivity through a 10/100/1000 Mbps RJ45 interface
Supports multi-mode and single-mode fiber through the appropriate SFP module
Flexible transmission distance based on the selected SFP transceiver
Auto-negotiation for Ethernet speed and duplex operation
Auto MDI/MDIX support on the RJ45 interface
Front-panel LED indicators for power and link/activity status
Compact standalone design with external power supply
Suitable for extending Ethernet connectivity over fiber-optic networks
Technical Specifications
| Specification | Prime Connect 4055s |
|---|---|
| Standards & Protocols | IEEE 802.3 Ethernet, IEEE 802.3u Fast Ethernet, IEEE 802.3ab Gigabit Ethernet, IEEE 802.3z Gigabit Fiber Ethernet, IEEE 802.3x Flow Control |
| RJ45 Interface | 1 × 10/100/1000 Mbps RJ45 port |
| Fiber Interface | 1 × 1000 Mbps open SFP slot |
| SFP Compatibility | Compatible with suitable 1000BASE-X SFP transceiver modules |
| Fiber Type | Multi-mode Fiber (MMF) or Single-mode Fiber (SMF), depending on the installed SFP module |
| Copper Network Media | Category 5/5e or better UTP/STP Ethernet cabling |
| Copper Transmission Distance | Up to 100 m under standard Ethernet cabling conditions |
| Fiber Transmission Distance | Dependent on the installed SFP module; supported distance varies by transceiver and fiber type |
| Wavelength | Determined by the installed SFP transceiver |
| Operating Mode | Auto-negotiation of Ethernet speed and half/full-duplex operation |
| Auto MDI/MDIX | Supported on RJ45 interface |
| Flow Control | IEEE 802.3x |
| LED Indicators | Power, Link/Activity and Gigabit status |
| Power Supply | External DC power adapter |
| Power Consumption | Approx. 1.7 W |
| Dimensions | Approx. 94.5 × 73.0 × 27.0 mm (W × D × H) |
| Enclosure | Compact metal enclosure with ventilation openings |
| Installation | Standalone desktop installation |
| Operating Temperature | 0°C to 50°C |
| Storage Temperature | -40°C to 70°C |
| Operating Humidity | 10% to 90% RH, non-condensing |
| Storage Humidity | 5% to 90% RH, non-condensing |
| Compliance | Designed with applicable Ethernet and EMC/environmental compliance requirements in mind |
