ON-6FLIU 6 Fiber Rack-Mount Sliding Optical Fiber Interconnection Unit
The Optech Network Solutions ON-6FLIU is a compact, 19-inch rack-mount sliding Optical Fiber Interconnection Unit designed for organized optical fiber termination, interconnection, cross-connection, splicing, and fiber management. The sliding architecture provides convenient access to the internal fiber-management area during installation and maintenance. The unit provides space for optical cable installation, fiber splicing and protection, pigtail storage, and organized fiber routing. The ON-6FLIU is suitable for optical fiber networks, telecommunications networks, FTTx deployments, Outside Plant (OSP) applications, and structured fiber infrastructure.
Key Features
Technical Specifications
| Specification | ON-6FLIU 6 Fiber Rack-Mount Sliding Optical Fiber Interconnection Unit |
|---|---|
| Product Type | Rack-Mount Sliding Optical Fiber Interconnection Unit |
| Fiber Capacity | 6 Fiber |
| Mounting | 19-inch Standard Rack Mount |
| Rack Height | 1U (44.4 mm) |
| Dimensions | 480 × 310 × 44.4 mm |
| Suitable Adapter | SC / FC / LC / ST |
| Material | Cold Rolled Steel |
| Cable Entry | 20 mm |
| Surface Finish | Powder Coating |
| Operating Temperature | -40°C to +60°C |
| Application | Fiber Termination, Splicing, Interconnection and Cross-Connection |
