Optech Network Solutions Prime Connect 4056s
The Optech Network Solutions Prime Connect 4056s is an industrial serial-to-fiber converter designed to extend RS-232, RS-422 and RS-485 communication over fiber-optic networks. It provides reliable electrical isolation between serial equipment and fiber infrastructure while reducing the impact of electromagnetic interference and electrical disturbances. The Prime Connect 4056s supports both multi-mode and single-mode fiber configurations, with the achievable transmission distance determined by the selected optical interface and fiber type. It is suitable for industrial automation, utility communication, SCADA, remote equipment monitoring and other applications where serial communication needs to be extended over longer distances. The converter supports serial communication speeds up to 921.6 kbps and can operate in point-to-point or fiber-ring network configurations, making it suitable for both simple and redundant communication architectures.
Key Features
Technical Specifications
| Specification | Optech Network Solutions Prime Connect 4056s |
|---|---|
| Product Type | Industrial RS-232/RS-422/RS-485 to Fiber Converter |
| Serial Interfaces | RS-232, RS-422, RS-485 |
| Number of Serial Ports | 2 serial interface channels |
| Supported Serial Modes | RS-232, RS-422, RS-485 |
| Baud Rate | 50 bps to 921.6 kbps |
| Non-Standard Baud Rates | Supported, subject to communication requirements |
| Data Direction Control | Automatic data-direction control for RS-485 |
| Network Topology | Point-to-point and fiber-ring configurations |
| Fiber Interface | Optical fiber interface supporting application-specific fiber transceiver configuration |
| Fiber Type | Multi-mode Fiber (MMF) / Single-mode Fiber (SMF) |
| Typical Fiber Distance | Up to 5 km with multi-mode fiber; up to 40 km with single-mode fiber, depending on optical configuration |
| Typical Wavelength | Approximately 850 nm for multi-mode; approximately 1310 nm for single-mode configuration |
| Fiber Connector | Available according to the selected Prime Connect 4056s optical interface configuration |
| RS-232 Signals | TxD, RxD, GND |
| RS-422 Signals | Tx+, Tx-, Rx+, Rx-, GND |
| RS-485 4-Wire Signals | Tx+, Tx-, Rx+, Rx-, GND |
| RS-485 2-Wire Signals | Data+, Data-, GND |
| RS-485 Termination | Configurable termination according to network requirements |
| RS-485 Biasing | Configurable pull-up/pull-down biasing |
| Latency | Low-latency serial-to-fiber conversion |
| Power Input | 12–48 VDC |
| Power Inputs | 1 |
| Overload Protection | Supported |
| Reverse Polarity Protection | Supported |
| Power Connection | Industrial terminal-block connection |
| Power Consumption | Approximately 70–140 mA at 12–48 VDC, depending on configuration and operating conditions |
| Housing | Heavy-duty metal enclosure |
| Ingress Protection | IP30 |
| Dimensions with Mounting Ears | Approximately 90 × 100 × 22 mm |
| Dimensions without Mounting Ears | Approximately 67 × 100 × 22 mm |
| Weight | Approximately 320 g |
| Installation | Wall mounting / panel mounting |
| Standard Operating Temperature | 0°C to 60°C |
| Wide-Temperature Option | -40°C to 75°C |
| Storage Temperature | -40°C to 85°C |
| Operating Humidity | 5% to 95% RH, non-condensing |
| Fiber Isolation | Provides isolation between serial electrical interfaces and the fiber communication link |
| EMI/Interference Protection | Designed to reduce susceptibility to electromagnetic and electrical interference |
| Status Indication | Power, serial communication and fiber-link status indicators |
| Enclosure Cooling | Passive cooling through enclosure design |
| Mounting Hardware | Mounting hardware appropriate to the selected installation configuration |
